Open the "Object Editor" by clicking the icon shown opposite or selecting "Plug-Ins > Prinect 2020 > PDF Toolbox > Object Editor...".

Undo last step

Redo.

Create rectangle

To create a rectangle with rounded corners, click this button while holding down the Shift key. A dialog displays where you can enter the settings for the corner shape. You can set a fixed value between 0.1 and 9999 mm for the radius or a relative radius between 0.1% and 50%.

You create a square if you hold down the Shift key while drawing the rectangle. If an image object is selected, it is clipped to a rectangle.

Create ellipse You create a circle by holding down the Shift key at the same time.

If an image object is selected, it is clipped to an ellipse.

Edit the path or (if an image object is selected) create a clip path. For more details, see Editing the path with the Path Editor.

Select all objects.

Select all objects with same color as marked object.

Select all objects with same type as marked object.

For text objects only:

Select text block.

Select text line.

Select all text with same font type as marked text.

Select all text with same font size type as marked text.

Take color value from document.

Use colors for "Fill" and "Margin" of the marked object.

Create a PDF file with the marked objects.
